Line Encoding Bitstreams with Ragel

/* lc -- Line encode a bitstream with output in WaveDrom format.
   Copyright (C) 2022 Remington Furman
   This program is free software: you can redistribute it and/or modify
   it under the terms of the GNU General Public License as published by
   the Free Software Foundation, either version 3 of the License, or
   (at your option) any later version.
   This program is distributed in the hope that it will be useful,
   but WITHOUT ANY WARRANTY; without even the implied warranty of
   MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
   GNU General Public License for more details.
   You should have received a copy of the GNU General Public License
   along with this program.  If not, see <https://www.gnu.org/licenses/>.
 */

#include <stdio.h>
#include <string.h>
#include <getopt.h>
#include <stdlib.h>

struct line_code
{
    int cs;   /* Current state. */
    int bit;  /* Current bit value. */
};

%%{
    machine line_code;
    access fsm->;

    action low     { fsm->bit  = 0;  putchar('l'); }
    action high    { fsm->bit  = 1;  putchar('h'); }
    action toggle  { fsm->bit ^= 1;  putchar(fsm->bit ? 'h' : 'l'); }
    action toggle2 { fsm->bit ^= 1;  putchar(fsm->bit ? 'h' : 'l');
                     fsm->bit ^= 1;  putchar(fsm->bit ? 'h' : 'l'); }
    action hold    {                 putchar('.'); }
    action nl      {                 putchar('\n'); }

    zero_low_h  = ('0' @low  ('0' @hold)*); # Emit one  low then hold for rest
    zero_high_h = ('0' @high ('0' @hold)*); # Emit one high then hold for rest
    one_low_h   = ('1' @low  ('1' @hold)*); # Emit one  low then hold for rest
    one_high_h  = ('1' @high ('1' @hold)*); # Emit one high then hold for rest

    # Line code machines
    nrz_l := ((zero_low_h  | one_high_h )** 0 @nl)*; # Non-return-to-zero level
    nrz_i := ((zero_high_h | one_low_h  )** 0 @nl)*; # Non-return-to-zero invert
    nrz_s := (('0' @toggle | '1' @hold  )*  0 @nl)*; # Non-return-to-zero space
    nrz_m := (('0' @hold   | '1' @toggle)*  0 @nl)*; # Non-return-to-zero mark

    bph_l := (('0' @low @high    | '1' @high @low   )* 0 @nl)*; # Bi-phase level
    bph_s := (('0' @toggle2      | '1' @toggle @hold)* 0 @nl)*; # Bi-phase space
    bph_m := (('0' @toggle @hold | '1' @toggle2     )* 0 @nl)*; # Bi-phase mark

    # Aliases
    pass   := any @{ fhold; fgoto nrz_l; };
    invert := any @{ fhold; fgoto nrz_i; };
    manch  := any @{ fhold; fgoto bph_l; };
    main   := any @{ fhold; fgoto nrz_l; };
}%%

%% write data;

void line_code_init(struct line_code *fsm, int first_bit, int start)
{
    fsm->bit = first_bit;

    %% write init;

    fsm->cs = start;
}

void line_code_execute(struct line_code *fsm, const char *data, int len)
{
    const char *p = data;
    const char *pe = data + len;

    %% write exec;
}

int line_code_finish(struct line_code *fsm)
{
    if (fsm->cs == line_code_error) {
        return -1;
    }

    if (fsm->cs >= line_code_first_final) {
        return 1;
    }
    return 0;
}

#define NUM_ELEMENTS(a) (sizeof(a)/sizeof(a[0]))
#define XSTRINGIFY(s) #s
#define STRINGIFY(s) XSTRINGIFY(s)
#define MACHINE(name, desc) { STRINGIFY(name), desc, &line_code_en_ ## name }

struct { const char *name; char* desc; const int *start; } machines[] = {
    MACHINE(nrz_l,  "Non-return-to-zero level"),
    MACHINE(nrz_i,  "Non-return-to-zero invert"),
    MACHINE(nrz_s,  "Non-return-to-zero space"),
    MACHINE(nrz_m,  "Non-return-to-zero mark"),
    MACHINE(bph_l,  "Bi-phase level"),
    MACHINE(bph_s,  "Bi-phase space"),
    MACHINE(bph_m,  "Bi-phase mark"),
    MACHINE(pass,   "Passthrough (alias of nrz_l)"),
    MACHINE(invert, "Invert (alias of nrz_i)"),
    MACHINE(manch,  "Manchester (alias of bph_l)"),
};

void usage(char *name) {
    printf("%s [flags] input" , name);
    printf("    input\n"
           "        One or more strings of 0's and 1's\n"
           "    -i n\n"
           "        Initial line state (default: 0)\n"
           "    -c name\n"
           "        Line code to use (default: pass)\n");
    printf("\nAvailable codes:\n");
    for (int i = 0; i < NUM_ELEMENTS(machines); i++) {
        printf("  %-7s- %s\n", machines[i].name, machines[i].desc);
    }
}

int main(int argc, char **argv)
{
    struct line_code lc;

    int first_bit = 0;
    int start = line_code_en_nrz_l;

    int opt;
    while ((opt = getopt(argc, argv, "f:m:h")) != -1) {
        switch (opt) {
            case 'f': {
                first_bit = !!atoi(optarg);
                break;
            }
            case 'm': {
                int found = 0;
                for (int i = 0; i < NUM_ELEMENTS(machines); i++) {
                    if (strcmp(optarg, machines[i].name) == 0) {
                        start = *machines[i].start;
                        found = 1;
                        break;
                    }
                }
                if (!found) {
                    printf("Invalid machine name: %s\n", optarg);
                    usage(argv[0]);
                    exit(EXIT_FAILURE);
                }
                break;
            }
            case 'h': {
                usage(argv[0]);
                exit(EXIT_SUCCESS);
                break;
            }
            default: {
                usage(argv[0]);
                exit(EXIT_FAILURE);
                break;
            }
        }
    }

    /* Initialize state machine */
    line_code_init(&lc, first_bit, start);

    for (int i = optind; i < argc; i++) {
        /* Encode each input argument. */
        line_code_execute(&lc, argv[i], strlen(argv[i])+1);
    }

    if (line_code_finish(&lc) != 1) {
        fprintf(stderr, "%s: bad input\n", argv[0]);
        usage(argv[0]);
        exit(EXIT_FAILURE);
    }

    return 0;
}

{signal: [
  {name: 'pass',   wave: 'lhl.h.l..h..l...h...'},
  {name: 'invert', wave: 'hlh.l.h..l..h...l...'},
  {name: 'nrz_l',  wave: 'lhl.h.l..h..l...h...'},
  {name: 'nrz_i',  wave: 'hlh.l.h..l..h...l...'},
  {name: 'nrz_s',  wave: 'h.lh..lhl...hlhl....'},
  {name: 'nrz_m',  wave: '.h..lh...lhl....hlhl'},
  {name: 'manch',  wave: 'lhhllhlhhlhllhlhlhhlhlhllhlhlhlhhlhlhlhl'},
  {name: 'bph_l',  wave: 'lhhllhlhhlhllhlhlhhlhlhllhlhlhlhhlhlhlhl'},
  {name: 'bph_s',  wave: 'hlh.lhlhl.h.lhlhlhl.h.l.hlhlhlhlh.l.h.l.'},
  {name: 'bph_m',  wave: 'h.lhl.h.lhlhl.h.l.hlhlhlh.l.h.l.hlhlhlhl'},
]}
